Twin screw
Lines
Lines
Twin Screw co-rotating Compounding line with processing flexibility and modular construction having different torque and motor capacity options makes it easy to select right extruder for process needs.
Processing flexibility with Modular construction
Different torque and motor capacity options makes it easy to select right extruder for process needs.
Higher torque density is offered in its class leading to high flexibility in using extruder to process very wide range of formulations.
Longer life through reliable components
Heavy duty gear box in its class. High torque aailability helps with processing and longer operating life. Barrel segments with bi-metallic liners. Screw elements available with various metallurgy.
Dependable after Sales Service
Challenging processing conditions with compounding needs very strong and efficinet serice support. Traditionally strong after sales serice of Kabra Extrucsiontechnik through unique initiative of KOLSITE KONNECT feels operating staff at home
| Model | Screw diameter (mm) | Throughput (Kgs/hr) |
|---|---|---|
| TSK 31 | 31 | 75 |
| TSK 36 | 36 | 150 |
| TSK 42 | 42 | 300 |
| TSK 50 | 50 | 400 |
| TSK 57 | 57 | 500 |
| TSK 72 | 72 | 1000 |
| TSK 91 | 91 | 1500 |
| TSK 96 | 96 | 2000 |
